Máy hiện sóng, Oscilloscope Siglent SDS1202CFL, 200 MHz, 2 CH

Máy hiện sóng, Oscilloscope Siglent SDS1202CFL, 200 MHz, 2 CH

21,800,000  19,620,000

• Hãng sản xuất

Model

Bảo hành

Siglent

SDS1202CFL

12 tháng

Để có giá tốt nhất và nhanh nhất, vui lòng liên hệ

(028) 3977 8269 – (028) 3601 6797

Email: sales@lidinco.com – lidinco@gmail.com

Đặc biệt: có máy cho mượn trong lúc chờ đặt hàng (điện thoại để biết thêm chi tiết)

  • Mô tả
  • Thông tin bổ sung
  • Thông số kỹ thuật

Mô tả

Máy hiện sóng để bàn Siglent sds1202

Máy hiện sóng để bàn Siglent sds1202

Máy hiện sóng  Siglent SDS 1202CFL

  • Băng thông 200 MHz
  • Lấy mẫu 2 GSa/s, 2 kênh,
  • Bộ nhớ 24 kpts/kênh
  • Màn hình 7 inch.
  • Sản phẩm được phân phối bán lẻ và bảo hành chính hãng bởi Lidinco





Application software
EasyScope3.0 software can connect the SDS1000 series DSO to the PC through USB serial interface or RS-232 interface
The software can afford controling and analysing function such as following items:
1:Display the captured waveforms,datas and measurement value by the display areas.
2:Control the local and distant operation by the DSO control.ler.
3:Save the picture as “BMP” format
4:Save the data to “EXCEL”file,easy to analyse
5:Print or save waveforms
.

Thông tin bổ sung

Hãng SX

Siglent

Model/Index SDS1202CFL
Bandwidth 200MHz
Channel 2 channels+1 ext trig
Real Time Sampling Half Channel:2GSa/s;Each Channel:1GSa/s
Equivalent Sampling Rate 50GSa/s
Memory Depth Single Channel:24K
Rise time <1.2ns
Input Impedance 1MΩ||13pF,50Ω
Sec/div Range 2.5ns/div-50s/div
Vertical Sensitivity 2mv-5v/div(1-2-5 sequence)
Vertical Resolution 8bit
Display Color TFT(480*234) 7" LCD

CHARACTERISTIC:

● Memory depth of SDS1000CFL is 24Kpts

● Use Colored TFT LCD, the waveform display is clearer and stable.

● Screen saver function:1 minute to 5 hours

● 02 channel-channel bandwidth: 200MHz.

● The real time sampling rate is 2GSa/s.

● Trigger Modes: Edge, Pulse, Video, Slope and Alternative trigger modes.

● Unique Digital Filter function and Waveform recorder function

● Pass/Fail function

●Thirty two parameters Auto measure function.

● Cursor measure covers Manual mode, Track mode and Auto mode.

● Channel waveform and it’s FFT waveform display on split screen.

● Pop-up Menu display pattern is more convenient for users using it.

● Multiple Language User Interface.

● Support Multilingual online help system.

Model/Index The Common Specifications Of All SDS1000D Series Products
Display 8X18 divides
Waveform Capture Rate The highest capture rate exceed 1500 times/sec
Input coupling DC, AC, GND
Input Max voltage 400V(Vpp)
Trigger Types Edge, Pulse, Video, Slope, Alternative
Trigger Modes Auto, Normal, Single
Trigger Source CH1、CH2、CH3、CH4、Ext、Ext/5、AC Line
Save/Recall Provide four groups reference waveforms, twenty groups capture waveforms and twenty groups setups internal save/recall function and USB flash drive Save/Recall function
Auto Measure Types Vpp, Vmax, Vmin, Vamp, Vtop, Vbase, Cmean, Mean, Vrms, Crms, ROVShoot, FOVShoot, RPREShoot, FPREShoot, Freq, Period, Rise time, Fall Time, +Width, -Width, +Duty, - Duty, BWid, Phase, FRR, FRF, FFR, FFF, LRR, LRF, LFR, LFF
Cousor measure Manual, Track, Auto
Sample Types Real Time, Equivalent Time
Averages 4、16、32、64、128、256
Math +、-、*、\、Invert
FFT Window: Hanning、Hanmming、Blackman、Rectangular
Sampling Points: 1024 points
XY Mode Phase Error: ±3 degrees
Support the sampling rate : 10KSa/s~1GSa/s (in a 1-2-5 sequence)
Display Model Main, Window, Window Zoom, Roll, X-Y
Menu Display 2Sec, 5Sec, 10Sec, 20Sec, Infinite
Display Language Simplified Chinese, Traditional Chinese, English, Arabic, French, German, Russian, Spanish, Portuguese, Japanese, Korean, Italiana
Power Source Voltage 100-240VAC、45HZ-440HZ、50VA Max
Size and Weight 358mm x 156mm x118mm, about 4.5kg
Connection USB Host: Support USB flash drive storage
USB Device: Support PictBridge compatible printers and PC Remote control
RJ-45(LAN): Support computer connecting
Pass/Fail Interface Module
Accessories (1:1、10:1)Problex 4, EasyScope3.0 Computer Software System, Power Cord, USB cable,User Manual, EasyDsoLib software package
