About Manual Office Guillotine EBA 4705:

Powerful manual office guillotine with 475 mm cutting length and 70 mm cutting height. SCS - the Safety Cutting System made by EBA provides numerous safety features: hinged, transparent safety guard on the front table (locks automatically while cutting); transparent safety cover on the rear table; safety catch (locks blade lever in upper position); safe and convenient blade change from the front without removing machine covers; blade changing device with covered cutting edge; blade depth adjustment from the outside of the machine; cutting stick can be turned or replaced easily from the outside of the machine. Blade made of German high quality steel. Solid steel blade carrier. Adjustable blade guides made of hardened steel. Solid spindle clamp with hand wheel. Spindle guided back gauge with hand crank. Measuring scale (mm/inches) on front table. Solid all-metal construction. Designed as table top machine, a stand is available as an option (at an extra cost).

Features:

Cutting stick change:

Turning or exchanging the cutting stick can easily be managed from the outside of the guillotine without using any tools.

Measuring scale:

The precise measuring scale (mm / inches) located on the front table of this guillotine allows precise positioning of the back gauge.

Spindle clamp with hand wheel:

The variable clamp pressure is applied via the hand wheel to both ends of the clamp for firm pressure across the entire cutting line.

Hand crank:

The calibrated hand crank and the measuring tape on the side lay ensure the exact positioning of the back gauge.

Transparent safety guard:

The hinged safety guard has to be closed to unlock the blade lever for the cutting process.

Specifications:

Dimensions and weight:

Height: 590 mm
Width: 1000 mm
Depth: 890 mm
Weight: 85 kg

Height with stand: 1270 mm
Weight with stand: 93 kg

Cutting length: 475 mm

Cutting height: 70 mm

Narrow cut: 30 mm

Table depth: 455 mm
