The SPP series programmable DC power supply is a switching mode DC power supply with a USB interface for communication. The maximum power can reach 6KW, and the SPP series can be fully customized with a maximum voltage of 1000V and a maximum current of 300A.

Features

✓ Maximum output power range from 500W to 6kW
✓ Maximum maximum output voltage 1000V output current 300A
✓ MCU digital control and advanced PWM adjustment
✓ Compact design and light weight
✓ Constant voltage (CV) and constant current (CC) operation; automatic CV/CC switching
✓ Coarse and fine adjustment control of voltage and current
✓ Over-voltage, over-current, and over-temperature protection functions
✓ Built-in buzzer alarm
✓ Panel lock and output ON/OFF function
✓ Intelligent temperature-controlled cooling fan
✓ USB interface, supports MODBUS-RTU commands
✓ USB interface can be changed to RS232 or RS485 interface upon request
✓ Accepts customized specifications and functions

Model	Rated Voltage	Rated Current	Rated Power	Display Resolution
M chassis, 200Wx150Hx285D mm, 200W~1800W
SPP5-120	0~5V	0~120A	600W	1mV	100mA
SPP15-30	0~15V	0~30A	450W	10mV	10mA
SPP15-50	0~15V	0~50A	750W	10mV	10mA
SPP15-60	0~15V	0~60A	900W	10mV	10mA
SPP15-80	0~15V	0~80A	1200W	10mV	10mA
SPP15-100	0~15V	0~100A	1500W	10mV	100mA
SPP30-20	0~30V	0~20A	600W	10mV	10mA
SPP30-30	0~30V	0~30A	900W	10mV	10mA
SPP30-40	0~30V	0~40A	1200W	10mV	10mA
SPP30-50	0~30V	0~50A	1500W	10mV	10mA
SPP30-60M	0~30V	0~60A	1800W	10mV	10mA
SPP50-20	0~50V	0~20A	1000W	10mV	10mA
SPP50-30	0~50V	0~30A	1500W	10mV	10mA
SPP60-10	0~60V	0~10A	600W	10mV	10mA
SPP60-20	0~60V	0~20A	1200W	10mV	10mA
SPP60-30M	0~60V	0~30A	1800W	10mV	10mA
SPP100-5	0~100Vv	0~5A	500W	100mV	1mA
SPP100-6	0~100V	0~6A	600W	100mV	1mA
SPP100-10	0~100V	0~10A	1000W	100mV	10mA
SPP100-15	0~100V	0~15A	1500W	100mV	10mA
SPP120-5	0~120V	0~5A	600W	100mV	1mA
SPP120-10	0~120V	0~10A	1200W	100mV	10mA
SPP150-3	0~150V	0~3A	450W	100mV	1mA
SPP150-5	0~150V	0~5A	750W	100mV	1mA
SPP150-10	0~150V	0~10A	1500W	100mV	10mA
SPP200-1	0~200V	0~1A	200W	100mV	1mA
SPP200-2	0~200V	0~2A	400W	100mV	1mA
SPP200-3	0~200V	0~3A	600W	100mV	1mA
SPP200-5	0~200V	0~5A	1000W	100mV	1mA
SPP220-1	0~220V	0~1A	220W	100mV	1mA
SPP220-2	0~220V	0~2A	440W	100mV	1mA
SPP220-3	0~220V	0~3A	660W	100mV	1mA
SPP220-5	0~220V	0~5A	1100W	100mV	1mA
SPP250-1	0~250V	0~1A	250W	100mV	1mA
SPP250-2	0~250V	0~2A	500W	100mV	1mA
SPP250-3	0~250V	0~3A	750W	100mV	1mA
SPP250-4	0~250V	0~4A	1000W	100mV	1mA
SPP250-5	0~250V	0~5A	1250W	100mV	1mA
SPP300-1	0~300V	0~1A	300W	100mV	1mA
SPP300-2	0~300V	0~2A	600W	100mV	1mA
SPP300-3	0~300V	0~3A	900W	100mV	1mA
SPP300-5	0~300V	0~5A	1500W	100mV	1mA
SPP400-1	0~400V	0~1A	400W	100mV	1mA
