Specification

Test Parameter: |Z|, C, L, X, B, R, G, D, Q, θ

Basic Accuracy: 0.05%

Equivalent Circuit: Series and Parallel

Math Function: Deviation and Percent Deviation

Ranging Mode: Auto, Hold

Trigger Mode: Internal, Manual, External and Bus

Measuring Speed: Slow: 1.5meas/sec Med: 10meas/sec Fast: 30meas/sec

Correction Function: Open, Short and Load corrections

Measurement Terminal: 5 terminals

Averaging Rate: 1—255 , TH2816A/TH2817A only

Delay Time: 0—60sec , with step of 1ms

List Sweep: List sweep for up to 4 frequencies, signal levels and DC bias levels

Display Mode: Direct, ΔABS, Δ%, V/I( V/I monitor), Bin number and bin counter

Display: 240×64 dot-matrix LCD display, 6-digit resolution

Signal Frequency:

50Hz to 100kHz: 50Hz, 60Hz, 100Hz, 120Hz, 200Hz, 400Hz, 500Hz, 1kHz, 2kHz, 4kHz, 5kHz, 10kHz, 20kHz, 40kHz, 50kHz, 100kHz , 16 points

Output Impedance: 30Ω , 100Ω

Test Level: 10mVrms to 2.0Vrms, 10mV steps

θ(RAD): -3.14159 — 3.14159

Δ%: -999.999% — 999.999%

Comparator Function: Bins( BIN1 to BIN3, OUT of bins), and additional AUX bin

Memory: Control settings memory for store/recall

Interface: RS-232C, HANDLER, GPIB (Optional)

|Z|, R,X: 0.00001Ω — 99.9999MΩ

C: 0.00001pF — 999.999mF

L: 0.00001μH — 9.99999kH

G,B: 0.00001μS — 999.999S

D: 0.00001 — 9.99999

Q: 0.00001 — 99999.9

θ(DEG): -179.999º — 179.999º

Description product
Accessories

Brief Introduction

TH2817A is a new precision LCR meter combined with years of technical experience and newest measurement technology of instrument industry. With powerful measurement functions, high performance and low cost, TH2817A has been one of the world advanced instruments, and it provides users a super value measurement resolution and experience. The meter offers stable 6 digit resolution, wide frequency range (50Hz to 100kHz for TH2817A ), programmable signal level (0.01V to 2.0V), up to 30 meas/sec measurement rate, 9 measurement ranges, 30Ω or 100Ω constant output impedance and friendly operation interface. TH2817A can be used for incoming inspection of components, quality control of product line and high accuracy laboratory use. The HANDLER, GPIB, RS232C interfaces make it easy to build an automatic component test system,
