Description

The TP600W series are linear DC power supplies with 2 channels, 600W output. In constant voltage and current operations, the power supply provides high regulation and low ripple & noise. Auto series and parallel operations double output voltage and current. Automatic cooling fan control give sufficient cooling to the power supply and minimize fan noise. The output ON/OFF control and preset voltage & current function protect the power supply and related loads from unexpected damages. The TP600W series are widely used in applications of powering operational amplifier, push pull stages, logic circuit and definition systems

Features

★ Two independent adjustable outputs 0~30V/0~10A ×2 (TP-30102), 0~60V/0~5A ×2 (TP-60052)

★ Constant voltage and constant current operations

★ Low ripple and noise, low temperature drift

★ Auto Series and Parallel tracking operations

★ Output ON/OFF control

★ Preset voltage and current

★ High efficiency, high power density

★ Over load and reverse polarity protections

★ Dual-color four digital panel meters

Specifications

Constant voltage operation
Line regulation		≤0.01%+3mV
Load regulation		≤0.02%+5mV
Ripple & Noise		≤2mVrms
Constant current operation
Line regulation		≤0.2%+3mA
Load regulation		≤0.2%+5mA
Ripple & Noise		≤6mArms
Tracking operation
Parallel	Line regulation	≤0.01%+3mV
	Load regulation	≤0.02%+5mV
Series	Line regulation	≤0.01%+5mV
	Load regulation	≤300mV
	Tracking error	≤0.5%+10mV of the master, no load (with load, add load regulation≤300mV)
Display
Voltmeter		3 digits LED display
Ammeter		4 digits LED display
Resolution		100mV/10mA
Accuracy		±(1% reading+2digits)
Protection		Over load and reverse polarity protections
Power source		AC110V, AC220V or AC110V/220V±10%, 50/60Hz
Operating environment		0℃~40℃, ≤80%RH
Storage environment		-10℃~70℃, ≤70%RH
Accessories		Power cord x1, Operation manual x1

Accessories

Power cord x1

Operation manual x1
