DC Power Supplies Siglent SPD1168X, 0~16V/0~8A

DC Power Supplies Siglent SPD1168X, 0~16V/0~8A

SKU:
SPD1168X
Brand:
Warranty:
N/A
6.300.000đ

(Price does not include VAT)

  • Output Voltage:
  • Output Current:
  • Output Channel:
  • DC Supply Type:
  • 1 products available
  • There are currently no promotions for this product

Hotline: +84 906 988 447

Head Office: Ho Chi Minh City

  • Tel: +84 2839 778 269 / 3601 6797
  • Email: sales@lidinco.com
  • Add: 487 Cong Hoa Street, Ward 15, Tan Binh Dist, HCM City, Vietnam

Office: Bac Ninh City

  • Tel: +84 222 730 0180
  • Email: bn@lidinco.com
  • Add: 184 Binh Than Street, Vo Cuong Ward, Bac Ninh City, Vietnam
  • Counseling Technical Counseling 100% Free
  • Shipping Free Shipping For 3.000.000vnd Order
Specification

1. DC output: 16 V, 8 A, 128 W

2. Display: 2.8 inch true color TFT-LCD screen, voltage 5 digits/line

3. Resolution: 1 mV / 1 mA

4. Constant voltage mode:

Load stability: 0.01% + 2 mV

Ripple and Noise: ≤ 350 uVrms / 3 mVpp (20 Hz to 20 MHz)

Recovery time: <50 μs (50% load change, 0.5 A min load)

5. Constant current mode:

Current stabilization: constant current mode 0.2% + 3 mA

Load stability: 0.2% + 3 mA

Ripple and Noise: 2 mArms

6. Output model: 2-wire output mode, 4-wire offset, Maximum offset voltage 1 V

7. Locking Key: Yes

8. Memory Save/Recall: 5 sets

9. AC power supply: 100/120/220/230 V ± 10% 50/60 Hz

10. Standard configuration interface: USB device, LAN

11. Insulation: Case to terminal ≥ 20 MΩ (DC 500 V) Case to AC line ≥ 30 MΩ (DC 500 V)

12. Operating environment: Outdoor Use: Altitude: ≤2000 m Ambient temperature: 0 to 40 ℃

Relative humidity 80% Installation degree: Pollution degree: 2

13. Storage environment: Ambient Temperature: -10 to 70 Relative humidity 70%

14. Dimensions: 154.6 (W) × 144.5 (H) × 280 (D) mm

15. Weight: 5.5 kg

16. Channel Output: 16 V / 8 A

17. Setting accuracy:  Voltage: ± (0.03% reading + 10 mV) Current: ± (0. 3% reading + 10 mA)

18. Re-reading accuracy: Voltage: ± (0.03% of reading + 10 mV) Current: ± (0. 3% of reading + 10 mA)

Description

SPD1168X Programmable Linear DC Power Supply has a 2.8 inch TFT-LCD display, features remote computer control capability, ity and real time wave display, to deliver high performance and ease-of-use. The SPD1168 features a high precision programmable output capable of delivering up to 16 V and also includes a 4-wire sense function for more accurate voltage sourcing, especially for long leads or high resistance connections. There are additional output short and overload protect functions to assist in production and development applications.

Features

  • Single path high-precision programmable voltage output:16 V/8 A,total power up to 128 W
  • Stable, reliable, Low ripple and noise:≤ 350 uVrms/3 mVpp; < 2 mArms
  • Fast transient response time: < 50 μs
  • 5 digit Voltage, 4 digit Current Display, Minimum Resolution: 1 mV/1 mA
  • Supports front panel timing output functions
  • 2.8 inch true color TFT- LCD 240 *320 display
  • 2 types of output modes:Two-wire output mode, 4-wire compensation output mode,Maximum compensation voltage 1V
  • 100/120/220/230 V compatible design to meet the needs of different power grids
  • Intelligent temperature-controlled fanreduces noise
  • Clear graphical interface, with the waveform display function
  • Internal 5 groups of system parameter save/recallIncludes PC software: Easypower, supports SCPI, LabView driver

Accessories

  • USB Cable -1
  • Quick Start -1
  • Calibration Certificate -1
  • Power cord -1
  • Output Test Cord -2 Sets
