Handheld Oscilloscope Siglent SHS1102, 100MHz, 2 channel Isolated

Handheld Oscilloscope Siglent SHS1102, 100MHz, 2 channel Isolated

SKU:
SHS1102
Brand:
Warranty:
N/A
Price: Contact
  • Please contact to check stock
  • There are currently no promotions for this product

Hotline: +84 906 988 447

Head Office: Ho Chi Minh City

  • Tel: +84 2839 778 269 / 3601 6797
  • Email: sales@lidinco.com
  • Add: 487 Cong Hoa Street, Ward 15, Tan Binh Dist, HCM City, Vietnam

Office: Bac Ninh City

  • Tel: +84 222 730 0180
  • Email: bn@lidinco.com
  • Add: 184 Binh Than Street, Vo Cuong Ward, Bac Ninh City, Vietnam
  • Counseling Technical Counseling 100% Free
  • Shipping Free Shipping For 3.000.000vnd Order
Specification

Bandwidth: 100 MHz

Number of channels: 2 isolated channels

Rise time: 3.5 ns

True sampling rate: 1GSa/s

Equivalent sampling rate: 50 GSa/s

Time base: 2.5 nS/DIV ~ 50 S/DIV

Memory depth: 2 Mpts

Vertical Sensitivity: 5 mv~100 v/div

Vertical resolution: 8 bit

Modulation Type: Edge,Pulse,Video,Slope,Alternative

Data logging: 7 Mpts

Trend plot: 800 Kpts

Triggering Frequency Counter: 6 digits

Connectivity: USB Device, USB Host

Math function: +,-,*,/,FFT

Maximum resolution: 6000

DC voltage: 60mV – 1000V | ±1%±15 digits

AC voltage: 60mV – 750V | ±1.5%±15 digits

DC current: 60mA – 10A | ±5%±5 digits

AC current: 60mA – 10A | ±5%±5 digits

Capacitance: 40 nF | 400 nF-400 μF

Resistance: 600 Ω-6 MΩ | 60 USES

Open circuit: <50

Diodes: 0 – 2V

Trend Plot: 1.2Mpts

Display: 5.7 inch color TFT-LCD,320*234

Power: Rechargeable battery

Weight: 1.5kg

Dimensions: 163.2 mm * 259.5 mm * 53.3 mm

Description

Siglent’s SHS1000-series handheld digital oscilloscopes take advantage of years of SIGLENT research and development. It adopts many dedicated integrated circuits which allows for a simpler layout, low power consumption and a very small footprint.

Features:

- Completely isolated oscilloscope input channels, isolated between oscilloscope and multimeter channels
- Oscilloscope isolation level: CAT II 1000V and CATIII 600V
- Combines the functions of an oscilloscope, multimeter and recorder in one
- Supports waveform printing and USB storage
- 60MHz / 100MHz bandwidth, 2 input channels, 2Mpts memory depth
- 1 GSa/s real time sampling rate, 50 GSa/s equivalent sampling rate
- Equipped with high precision multimeter, providing multiple functions
- 3 kinds of cursor modes, 32 kinds of automatic waveform measurements
- 5.7 inches color TFT-LCD
- Supports trend plotting and long-duration data recorder function
