Digital Surface Profile Gauge Elcometer E224C-TI
Hotline: +84 906 988 447
Head Office: Ho Chi Minh City
- Tel: +84 2839 778 269 / 3601 6797
- Email: sales@lidinco.com
- Add: 487 Cong Hoa Street, Tan Binh Ward, Ho Chi Minh City, Vietnam
Office: Bac Ninh City
- Tel: +84 222 730 0180
- Email: bn@lidinco.com
- Add: 184 Binh Than Street, Vo Cuong Ward, Bac Ninh, Vietnam
-
Technical Counseling
100% Free
-
Free Shipping
For 3.000.000vnd Order
Type: Integral Gauge
Measurement Range: 0-500μm (0-20mils)
Probe Tip: Tungsten carbide tip 60° angle; Tip Radius: 50μm (2mil)
Accuracy: ±5% or ±5μm (±0.2mil)
Resolution: 1μm (0.1mil)
Gauge memory: Last 5
Reading rate: 50+ readings per minute
Menu structure: in 30+ languages
Waterproof & dust resistant: IP64
Bright colour screen: with permanent back light
USB power supply: via PC
Data output: USB to computer
On screen statistics
Number of readings: η
Mean (average): x
Standard deviation: σ
Highest reading: Hi
Lowest reading: Lo
Coefficient of variation: CV%
High & low limits; definable audible & visual alarms
Data Output: USB, Bluetooth®: to computer, Android™ & iOS5 devices
Elcometer Softwatre & USB Cable: Yes
Replaceable screen protectors : Yes
Protective case : Yes
Display Information : 2.4” (6cm) QVGA TFT display, 320 x 240 pixels
Battery Type: 2 x AA batteries, rechargeable batteries can also be used
Gauge Dimensions: 168 x 73 x 37mm
Gauge Weight: 218g (7.69oz)
Description Elcometer E224C-TI
The Elcometer E224C-BI Digital Surface Profile Gauge provides the very latest in surface profile measuring technology for measuring surface profile on either flat or curved surfaces.
Features Elcometer E224C-TI
Accurate Surface Profile Measurements
- Can be used in accordance with National and International Standards
- Temperature stable measurements
- Statistics are calculated and displayed in real time during inspection
- Live and batch readings graph format for instant analysis
- Measurement capability to ±5%
A Powerful Surface Profile Gauge
- User replaceable tough tungsten carbide tip, can be used for up to 20,000 surface profile readings
- USB and Bluetooth® data output to iPhone¹ or Android™ devices
- Measures surface profiles up to 500μm (20mils)
- Review batch data or last 20 readings in a graph format
- Integral & separate probe options for flat and convex² curved surface
Efficient Inspections
- Fast reading rate of 50+ per minute
- Integral and separate probe versions to suit your application
- Alpha numeric batch identification
- Compatible with ElcoMaster® software and ElcoMaster® Mobile App
- Powersave Mode with tap awake
Accessories
Elcometer 224 gauge
Glass zero tile
2 x calibration foils
Wrist harness
Plastic transit case
Protective case
Screen protector
Probe protection cap
2 x AA batteries
Test certificate
Operating instructions
USB cable & ElcoMaster® software
