Digital Indicator ID-C Mitutoyo 543-470B

Digital Indicator ID-C Mitutoyo 543-470B

SKU:
543-470B
Brand:
Warranty:
N/A
Price: Contact
  • Please contact to check stock
  • There are currently no promotions for this product

Hotline: +84 906 988 447

Head Office: Ho Chi Minh City

  • Tel: +84 2839 778 269 / 3601 6797
  • Email: sales@lidinco.com
  • Add: 487 Cong Hoa Street, Ward 15, Tan Binh Dist, HCM City, Vietnam

Office: Bac Ninh City

  • Tel: +84 222 730 0180
  • Email: bn@lidinco.com
  • Add: 184 Binh Than Street, Vo Cuong Ward, Bac Ninh City, Vietnam
  • Counseling Technical Counseling 100% Free
  • Shipping Free Shipping For 3.000.000vnd Order
Specification

Data is being updated

Description

This is a multifunction indicator that is reliable and easy to use.
The ABSOLUTE Digimatic Indicator ID-C offers you the following benefits:

  • The ABSOLUTE sensor means you don‘t have to carry out origin setting every time you power it on, saving you time and hassle.
  • GO/±NG judgement is performed by setting the upper and lower tolerances.
  • You can make simple calculations by a user-definable factor using the formula Ax (‚x‘ is spindle displacement).
  • Large character height of 11mm provides good readability.
  • Display 330° rotatable.
  • A function lock protects the display against unauthorised use.

Specification

DATA/HOLD:
Yes
Digital/Analog:
Digital
Inch-Metric:
Metric
Range:
25.4 mm
Digital step:
0,001 mm
Max. Permissible Error E MPE:
0,003 mm
Hysteresis:
0,002 mm
H MPE (Hysteresis):
0,002 mm
R MPE (Repeatability):
0,002 mm
Digimatic data output:
Yes
Measuring force:
≤1,8
Type:
EN ISO Standard
Protection:
IP42
Display:
LCD, character height 11 mm rotatable 330°
Max. response speed:
Unlimited
Alarm:
Low voltage, counting value composition error, overflow error, tolerance limit setting error
Stem Ø:
8 mm
Contact point:
Carbide ball, thread M 2.5 x 0.45 mm
Power supply:
1 battery SR-44
Battery life:
approx. 7000 hours
Delivered:
Including 1 battery
Mass:
190
ON/OFF:
Yes
ABS / INC (INC ZERO):
Yes
PRESET:
Yes
Selectable resolution:
Yes
GO/±NG judgement:
Yes
Calculation function (with formula):
Yes
Counting direction switchable:
Yes
