Engis Large-scale Precision Lapping System EJW-610

Engis Large-scale Precision Lapping System EJW-610

SKU:
EJW-610/710/910/1200L-3AL
Brand:
Warranty:
N/A
Price: Contact
  • Grinding Application:
  • Please contact to check stock
  • There are currently no promotions for this product

Hotline: +84 906 988 447

Head Office: Ho Chi Minh City

  • Tel: +84 2839 778 269 / 3601 6797
  • Email: sales@lidinco.com
  • Add: 487 Cong Hoa Street, Ward 15, Tan Binh Dist, HCM City, Vietnam

Office: Bac Ninh City

  • Tel: +84 222 730 0180
  • Email: bn@lidinco.com
  • Add: 184 Binh Than Street, Vo Cuong Ward, Bac Ninh City, Vietnam
  • Counseling Technical Counseling 100% Free
  • Shipping Free Shipping For 3.000.000vnd Order
Specification

Data is being updated



Description

In recent years, with components becoming larger and lapping processes requiring higher precision, we at Engis Japan have reinforced our product lineup of large-scale precision lapping systems. In addition to our standard models, the GNC series mounted with a high-precision facing unit and the bridge-type GNC have become available based on workpiece size accuracies.

Specififcations

Water-cooled spindle
(with a slow-start/stop function)
0 through 80 rpm
Main motor 610I: 200 V, 2.2 kW, 3-phase
710I: 200 V, 3.7 kW, 3-phase
910I: 200 V, 7.5 kW, 3-phase
1200I: 200 V, 11 kW, 3-phase
Standard surface plate size
(Outer diameter x Inner diameter)
610I: ø610 mm x ø210 mm 710I: ø710 mm x ø210 mm
910I: ø910 mm x ø310 mm 1200I: ø1200 mm x ø400 mm
Air cylinders 610I / 710I: Single axis, Max. 130 kg
910I: Single axis, Max. 200 kg
1200I: Single axis, Max. 300 kg
Roller-arm support method Three stations
Main power 610I / 710I: 200 V, three-phase 30 A
910I / 1200I: 200 V, three-phase 50 A
Main unit size 610 I / 710 I : 1500 mm W × 900 mm D × 2100 mm H
910 I : 1800 mm W × 1500 mm D × 2200 mm H
1200 I : 2200 mm W × 2000 mm D × 2300 mm H
Net weight  610I / 710I: 1300 kg
910I: 3000 kg
1200I: 4500 kg

Model vs Workpiece Size

Model
(Plate Surface Diameter)
Standard Ring Size
(Outer Diameter x Inner Diameter)
Workpiece Size
(Reference Size)
EJW-610I 286 mm x 250 mm 248 mm
EJW-710I 360 mm x 322 mm 320 mm
EJW-910I 435 mm x 385 mm 383 mm
EJW-1200I 500 mm x 452 mm 450 mm
EJW-1600I Custom-made 700 mm
EJW-2500I Custom-made 1000 mm
EJW-3200I Custom-made 1300 mm
